Gigabyte X870 Eagle WiFi7 X870 AM5 ATX

Gigabyte X870 Eagle WiFi7 — AMD X870 ATX Motherboard for AM5 Builds

The Gigabyte X870 Eagle WiFi7 is an entry-level X870 ATX motherboard for AMD Ryzen 9000, 8000, and 7000 series processors on the AM5 platform. With dual USB4 Type-C, Wi-Fi 7, three M.2 slots including one PCIe 5.0, a 14+2+2 phase VRM, and DDR5-8000 OC support, it delivers X870 platform connectivity at an accessible price.

UK-based seller
Tracked delivery across the UK
Genuine product from trusted distributors

Key Features

• Socket: AM5 (AMD Ryzen 9000 / 8000 / 7000 series)
• Chipset: AMD X870
• Form Factor: Standard ATX (305 x 244mm)
• Memory: 4x DDR5 DIMM, up to 256GB, DDR5-8000 (O.C.), AMD EXPO support
• Storage: 1x M.2 PCIe Gen 5.0 x4, 2x M.2 PCIe Gen 4.0 x4, 4x SATA 6Gb/s, RAID 0/1/10
• Networking: Realtek 2.5GbE LAN, Wi-Fi 7 (802.11be, 2.4/5/6GHz), Bluetooth 5.4
• Rear I/O: 2x USB4 Type-C (40Gbps, DP Alt), 1x USB 3.2 Gen 2 Type-A, 1x USB 3.2 Gen 1 Type-A, 4x USB 2.0, HDMI, Q-Flash Plus
• Internal: 1x USB 3.2 Gen 2x2 header (20Gbps), 1x USB 3.2 Gen 1 header
• Audio: Realtek HD Audio, 7.1-channel
• RGB: 3x Addressable Gen2 headers, 1x RGB header
• Warranty: 3 Years

Product Overview

The X870 Eagle WiFi7 is Gigabyte's entry-level X870 ATX board, offering the USB4 and Wi-Fi 7 connectivity mandated by the X870 platform specification at a competitive price. Dual USB4 Type-C ports on the rear panel support 40Gbps data transfer and DisplayPort Alt Mode. The 14+2+2 phase VRM with Thermal Armor Advanced and a single 8-pin plus 4-pin CPU power configuration provides adequate power delivery for mainstream Ryzen 9000 builds. Three M.2 slots including a Gen 5 slot cover fast NVMe storage needs, with EZ-Latch Plus for tool-free installation. Note that the rear USB Type-A port count is limited — only one Gen 2 and one Gen 1 port alongside four USB 2.0 ports. HDMI is a genuine rear panel output. Q-Flash Plus enables BIOS updates without a CPU installed.
