Gigabyte B550M Gaming Plus WiFi (Socket AM5/B650/DDR5/S-ATA 6Gb/s/Micro ATX)

• Model Number: B650M GAMING PLUS WF

• Web Address: www.gigabyte.com

• EAN: 4719331862213

• UPC: 889523042793

• Package Type: Retail

• Warranty: 3 Years

Performance

• Chipset: AMD B650

• CPU Interface: Socket AM5

• CPU Support:
  https://www.gigabyte.com/Motherboard/B650M-GAMING-PLUS-WIFI-rev-1x/support#support-cpu

• BIOS:

  • 1 × 256 Mbit flash

  • Use of licensed AMI UEFI BIOS

  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Memory

• RAM Technology: DDR5 (Dual Channel)

• RAM Slots: 4 × 288-pin

• RAM Speeds: Up to DDR5 8000 (O.C.)

• Max. Memory Support: 256 GB

Graphics

• On-Board Video: Processor with integrated graphics is required

Storage

• S-ATA 6 Gb/s Port(s): 4

• RAID: Raid 0/1/5/10

Networking

• LAN Speed: Realtek 2.5GbE LAN chip (2.5 Gbps / 1 Gbps / 100 Mbps)

• Wireless NIC: Wi-Fi 6

• Bluetooth: v5.3

Audio

• On-Board Audio:

  • Realtek Audio CODEC

  • High Definition Audio

  • 2 / 4 / 5.1 / 7.1-channel

Expansion Slots

• PCI Express 4.0 x16: 1

• PCI Express 3.0 x1: 1

Back Panel I/O

• Back PS/2 Keyboard/Mouse Port: 1

• Back USB 2.0 Port(s): 2

• Back USB 3.2 Port(s) Type-A Gen 1: 3

• Back USB 3.2 Port(s) Type-C Gen 1: 1

• Back HDMI Port(s): 1

• Back DisplayPort(s): 2

• Back Other Port(s):

  • 2 × SMA antenna connectors

Internal Connectivity

• 24-pin ATX Power: 1

• 8-pin ATX Power: 1

• USB 2.0 Header(s): 2

• USB 3.2 Header(s) Gen 1: 1

• Front Panel Audio Connector: 1

• TPM Header(s): 1

• Internal Other Port(s):

  • 2 × Addressable LED strip headers

  • 1 × RGB LED strip header

• Internal Button(s):

  • 1 × Q-Flash Plus

Physical Specifications

• Product Width: 244 mm

• Product Length: 244 mm

• Package Width: 27 cm

• Package Length: 27.5 cm

• Package Height: 7 cm

• Gross Weight: 1.42 kg

Features

• AMD Socket AM5: Supports AMD Ryzen 7000 Series / Ryzen 8000 / Ryzen 9000 Series Processors.

• Unparalleled Performance: 5+2+2 Phases Digital VRM Solution.

• Dual Channel DDR5: 4 × SMD DIMMs with AMD EXPO and Intel XMP Memory Module Support.

• SuperSpeed Storage: PCIe 4.0 x4 M.2 Connector.

• EZ-Latch: PCIe x16 Slot with Quick Release Design.

• Fast Networks: Wi-Fi 802.11ax and 2.5GbE LAN.

• Extended Connectivity: 2 × DP, HDMI.

• Smart Fan 6: Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP.

• Q-Flash Plus: Update BIOS Without Installing the CPU, Memory and Graphics Card.

Package Contents

• Motherboard

• Manual

• 2 × Antennas

• 1 × SATA cable

• I/O Shield
