Gigabyte B850M D3HP (AM5/B850/DDR5/S-ATA 6Gb/s/Micro ATX)

Brand: Gigabyte

General Information

• Model Number: B850M D3HP

• EAN: 4719331867058

• UPC: 889523046586

• Warranty: 3 Years

• Package Type: Retail

• Form Factor: Micro ATX

BIOS

• BIOS:

  • 1 x 256 Mbit flash

  • Use of licensed AMI UEFI BIOS

  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Processor

• CPU Interface: Socket AM5

• Chipset: AMD B850

• CPU Support: https://www.gigabyte.com/Motherboard/B850M-D3HP/support#support-cpu

Memory

• RAM Technology: DDR5 (Dual Channel)

• RAM Slots: 4 x 288-pin

• RAM Speeds: Up to DDR5 8200 (O.C.)

• Max. Memory Support: 256GB

Expansion Slots

• PCI Express 3.0 x16: 1

• PCI Express 5.0 x16: 1

Storage

• S-ATA 6Gb/s Port(s): 4

• RAID: Raid 0/1/10

M.2 Socket(s)

• 1 x PCIe Gen 5.0 x4

• 1 x PCIe Gen 4.0 x4

Networking

• LAN Speed: Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Audio & Graphics

• On-Board Audio:

  • Realtek Audio CODEC

  • High Definition Audio

  • 2/4/5.1/7.1-channel

• On-Board Video: Processor with integrated graphics is required

Rear I/O Ports

• PS/2 Keyboard/Mouse Port: 1

• USB 2.0 Port(s): 2

• USB 3.2 Port(s) Type-A Gen 1: 3

• USB 3.2 Port(s) Type-C Gen 1: 1

• HDMI Port(s): 1

• DisplayPort(s): 2

• LAN Port(s): 1

• Audio Jack(s): 3

• Other Port(s): 1 x Q-Flash Plus

Internal Connectors

• 24-pin ATX Power: 1

• 8-pin ATX Power: 1

• USB 2.0 Header(s): 2

• USB 3.2 Header(s) Gen 1: 2

• Front Panel Audio Connector: 1

• TPM Header(s): 1

Internal Other Port(s)

• 2 x Addressable RGB Gen2 LED strip headers

• 1 x RGB LED strip header

Physical Specifications

Product Dimensions

• Width: 244mm

• Length: 244mm

Package Dimensions

• Width: 26.5

• Length: 27

• Height: 5.5

• Gross Weight: 0.985

Features

• X3D Turbo Mode to unleash new era gaming performance.

• AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors.

• Digital 5+2+2 phases VRM solution.

• Dual Channel DDR5: 4 x DIMMs with AMD EXPO Memory Module Support.

• EZ-Latch: PCIe x16 Slot with Quick Release Design.

• Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.

• Ultra-Fast Storage: 2 x M.2 slots, including 1 x PCIe 5.0 x4.

• Fast Networking: GbE LAN.

• Extended Connectivity: 2 x DP, HDMI.

Package Contents

• Motherboard

• Manual

• Quick Installation Guide

• I/O Shield

• 1 x SATA cable

• One pack of M.2 thick/thin rubber pads

• Motherboard

• AM5

• B850

• DDR5

• Micro ATX

Gigabyte B850 AI TOP (AM5/B850/DDR5/S-ATA 6Gb/s/ATX)

• Model Number: B850 AI TOP

• EAN: 4719331866570

• UPC: 889523045893

• Package Type: Retail

• Warranty: 3 Years

• Web Address: www.gigabyte.com

BIOS

• BIOS:

  • 1 × 256 Mbit flash

  • Use of licensed AMI UEFI BIOS

  • PnP 1.0a

  • DMI 2.7

  • WfM 2.0

  • SM BIOS 2.7

  • ACPI 5.0

Platform

• Chipset: AMD B850

• CPU Interface: Socket AM5

• CPU Support: https://www.gigabyte.com/Motherboard/B850-AI-TOP/support#support-cpu

Memory

• RAM Technology: DDR5 (Dual Channel)

• RAM Slots: 4 × 288-pin

• RAM Speeds: Up to DDR5 8600 (O.C.)

• Max. Memory Support: 256 GB

Expansion Slots

• PCI Express 5.0 x16: 1

• PCI Express 4.0 x16: 1

Storage

• S-ATA 6Gb/s Ports: 4

• RAID Support: RAID 0 / 1 / 10

M.2 Sockets

• 2 × PCIe Gen 5.0 x4

• 1 × PCIe Gen 4.0 x4

Networking

• On-Board LAN:

  • 2 × Marvell AQtion AQC113C 10GbE LAN chips

  • (10 Gbps / 5 Gbps / 2.5 Gbps / 1 Gbps / 100 Mbps)

• Wireless NIC: Wi-Fi 7

• Wireless Technology: 802.11a, b, g, n, ac, ax, be (supporting 2.4 / 5 / 6 GHz carrier frequency bands)

• Bluetooth: v5.4

Audio

• On-Board Audio: Realtek ALC1220 CODEC

Video

• On-Board Video: Processor with integrated graphics is required

Rear I/O Ports

• USB 2.0 Ports: 4

• USB 3.2 Type-C Gen 1 Ports: 4

• USB 3.2 Type-A Gen 2 Ports: 3

• DVI-I Ports: 1

• LAN Ports: 2

• Audio Jacks: 2

• S/PDIF Output: 1

• Other Ports: 2 × SMA antenna connectors (2T2R)

• Buttons: 1 × Q-Flash Plus

Internal Connectivity

• 24-pin ATX Power: 1

• 8-pin ATX Power: 2

USB Headers

• USB 3.2 Gen 1 Headers: 1

• USB 3.2 Gen 2 Headers: 2

• USB 3.2 Gen 2x2 Headers: 1

Other Internal Connectors

• Front Panel Audio Connector: 1

• TPM Headers: 1

Internal Other Ports

• 3 × Addressable RGB Gen2 LED strip headers

• 1 × RGB LED strip header

• 1 × Noise detection header

• 2 × Temperature sensor headers

Internal Buttons

• 1 × Power

• 1 × Reset

Cooling

Thermal Design

• VRM Thermal Armor Advanced with M.2 Thermal Guard

Physical Specifications

• Form Factor: Standard ATX

• Product Width: 244 mm

• Product Length: 305 mm

Package Dimensions

• Package Width: 27.5 cm

• Package Length: 34 cm

• Package Height: 8 cm

Weight

• Gross Weight: 2.69 kg

Features

• Training your own AI on your desk

• DDR5 OC up to 8600 MT/s

• AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors

• Digital twin 16+2+2 phases VRM solution

• Dual Channel DDR5: 4 × DIMMs with AMD EXPO Memory Module Support

• WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation

• EZ-Latch Plus: PCIe and M.2 slots with Quick Release and Screwless Design

• EZ-Latch Click: M.2 heatsinks with screwless design

• Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW

• New Power Monitor in HWinfo for real-time monitoring on CPU power phases

• Ultra-Fast Storage: 3 × M.2 slots, including 2 × PCIe 5.0 x4

• Efficient Thermal: VRM Thermal Armor Advanced with M.2 Thermal Guard

• Blazing Fast Networks: Dual 10GbE LAN and Wi-Fi 7 and directional Ultra-high gain antenna

• Extended Connectivity: Rear USB-C support up to 40Gb/s, Front USB-C 20Gb/s, HDMI

• High-Res Audio: ALC1220 and High-End Audio Capacitor

• Ultra Durable PCIe Armor: The metal back plate of PCIe x16 slot for enhanced durability

• PCIe UD Slot X: PCIe 5.0 x16 slot with 10× strength for graphics card

Package Contents

• B850 AI TOP Motherboard

• Manual

• Quick Installation Guide

• 1 × Antenna

• 2 × SATA cables

• 1 × Noise detection cable

• 2 × Thermistor cables

• 1 × G Connector

• 1 × M.2 thermal pad

• 2 × Packs of M.2 thick/thin rubber pads

• Motherboard

• AM5

• B850

• Wi-Fi

This motherboard provides a modern platform for high-performance desktop systems, offering advanced memory support, high-speed networking, and multiple storage options suitable for demanding workstation, AI, and enthusiast PC builds.
