Corsair Frame 4500X LX-R RGB iCUE LINK Mid Tower Case - Black

The Corsair Frame 4500X LX-R RGB is a mid-tower PC case combining the FRAME modular system with iCUE LINK ecosystem compatibility. It features wraparound tempered glass panels, three pre-installed 120mm ARGB fans, dual 360mm radiator support and back-connect motherboard compatibility. Compatible with Mini-ITX, Micro-ATX, ATX and E-ATX motherboards (E-ATX up to 277mm wide).

UK-based seller
Tracked delivery across the UK
Genuine product from trusted distributors

Key Features

• Form Factor: Mid Tower — supports Mini-ITX, Micro-ATX, ATX and E-ATX (up to 277mm wide)
• Back Connect Compatible: Yes — supports reverse-connector motherboards
• Pre-installed Fans: 3 x 120mm ARGB fans
• Fan Support: Top 3x 120mm / 2x 140mm | Side 3x 120mm / 2x 140mm | PSU Shroud 2x 120mm | Bottom 1x 120mm | Rear 1x 120mm or 140mm
• Radiator Support: Top 240/280/360mm | Side 240/280/360mm | Rear 120/140mm
• Dust Filters: Bottom, Side
• GPU Clearance: Up to 460mm
• CPU Cooler Clearance: Up to 185mm
• PSU Clearance: Up to 250mm
• Expansion Slots: 8 horizontal (or 3 vertical)
• Storage: 1x 3.5" HDD bay, 2x 2.5" SSD bays
• Front I/O: 2x USB 3.2 Gen1 Type-A, 1x USB 3.2 Gen2 Type-C, 1x headphone/mic combo
• Includes GPU anti-sag stabilisation arm
• CORSAIR InfiniRail Fan Mounting System
• Anti-shatter film on glass panels
• Side Panel: Wraparound tempered glass (front + side)
• Chassis Material: Steel / Plastic / Tempered Glass
• Colour: Black

Product Overview

The Frame 4500X LX-R RGB combines the flexibility of the FRAME modular system with iCUE LINK-ready internals. The wraparound tempered glass design — covering both the front and main side — provides a clear view of the build, with anti-shatter film applied to the glass for added safety. The CORSAIR InfiniRail mounting system allows fans and radiators to be repositioned across top and side positions, each supporting up to a 360mm radiator. With a GPU clearance of 460mm and eight expansion slots, the case is well suited to large, high-performance graphics cards. Back-connect motherboard support and a GPU anti-sag stabilisation arm are included as standard.

Delivery & Fulfilment

This product is sold by TechFinder UK, a UK-based sole trader business. All hardware is sourced through established distribution partners. Orders are dispatched within 1–2 business days with tracked delivery across the United Kingdom.

Why Buy from TechFinder UK?

• UK-based sole trader — genuine products, real accountability
• Sourced through established distribution partners
• Secure checkout with buyer protection
• Tracked UK delivery, dispatched within 1–2 business days
• Pre- and post-purchase support available

Technical Specifications

• Case Type: Mid Tower
• Colour: Black
• Motherboard Support: Mini-ITX, Micro-ATX, ATX, E-ATX (up to 277mm wide)
• Back Connect Compatible: Yes
• Expansion Slots: 8 horizontal (or 3 vertical)
• Pre-installed Fans: 3 x 120mm ARGB
• Fan Support: Top 3x 120mm / 2x 140mm | Side 3x 120mm / 2x 140mm | PSU Shroud 2x 120mm | Bottom 1x 120mm | Rear 1x 120mm or 140mm
• Radiator Support: Top 240/280/360mm | Side 240/280/360mm | Rear 120/140mm
• Dust Filters: Bottom, Side
• Max GPU Length: 460mm
• Max CPU Cooler Height: 185mm
• Max PSU Length: 250mm
• PSU Support: ATX, Bottom Mount
• Drive Bays: 1x 3.5" internal, 2x 2.5" internal
• Front I/O: 2x USB 3.2 Gen1 Type-A, 1x USB 3.2 Gen2 Type-C, 1x headphone/mic combo
• Side Panel: Wraparound Tempered Glass (front + main side)
• Chassis Material: Steel / Plastic / Tempered Glass
• Dimensions (W x H x D): 256mm x 471mm x 499mm
• Net Weight: 9.10 kg
• Gross Weight: 11.60 kg
• Package Dimensions: 55.9cm x 57.2cm x 32.7cm
• Warranty: 2 Years Corsair Manufacturer Warranty

Package Contents

• Corsair Frame 4500X LX-R RGB iCUE LINK Mid Tower Case
• 3 x 120mm ARGB Fans
• GPU Anti-Sag Stabilisation Arm
• Case Accessory Box

Product Identification

Model: Corsair Frame 4500X LX-R RGB iCUE LINK Mid Tower Case - Black
MPN: CC-9011316-WW
UPC: 840440402794
