Gigabyte B760 DS3H WF6E GEN5 ATX Motherboard
Brand: Gigabyte
Model Number: B760 DS3H WF6E GEN5
EAN: 4719331872939
Website: www.gigabyte.com
Package Type: Retail
Warranty: 3 Years
General Information
-
Form Factor: Standard ATX
-
Chipset: Intel B760 Express
-
CPU Interface: Socket 1700
-
CPU Support:
https://www.gigabyte.com/Motherboard/B760-DS3H-WIFI6E-GEN5/support#support-cpu
BIOS
-
1 × 128 Mbit flash
-
Licensed AMI UEFI BIOS
-
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
-
RAM Technology: DDR5 (Dual Channel)
-
RAM Slots: 4 × 288-pin
-
RAM Speeds: Up to DDR5 7600 (O.C.)
-
Maximum Memory Support: 256 GB
Expansion Slots
-
PCI Express 5.0 ×16: 1
-
PCI Express 4.0 ×16: 4
Storage
-
SATA 6 Gb/s Ports: 4
-
RAID Support: RAID 0 / 1 / 5 / 10
Connectivity
Wired Networking
-
LAN: Realtek GbE LAN chip (1 Gbps / 100 Gbps / 10 Mbps)
Wireless
-
Wireless NIC: Intel Wi-Fi 6E AX210
-
Wireless Standards: 802.11a / b / g / n / ac / ax
-
Frequency Bands: 2.4 GHz / 5 GHz / 6 GHz
-
Bluetooth: v5.3
On-Board Audio
-
Codec: Realtek Audio CODEC
-
Audio Support: High Definition Audio, 2 / 4 / 5.1 / 7.1-channel
On-Board Video
-
Processor with integrated graphics required
Rear I/O Ports
-
PS/2 Keyboard/Mouse Port: 1
-
USB 2.0: 4
-
USB 3.2 Gen 2 Type-A: 1
-
USB 3.2 Gen 2x2 Type-C: 1
-
HDMI: 1
-
DisplayPort: 1
-
LAN (RJ-45): 1
-
Audio Jacks: 3
-
Antenna Connectors: 2 × (2T2R)
Internal Connectors
-
24-pin ATX Power: 1
-
8-pin ATX Power: 1
-
USB 2.0 Headers: 2
-
USB 3.2 Gen 1 Headers: 2
-
COM Port Header: 1
-
Front Panel Audio Connector: 1
-
TPM Header: 1
-
S/PDIF Out Header: 1
-
Addressable RGB Gen2 LED Strip Headers: 3
-
RGB LED Strip Header: 1
Internal Buttons
-
1 × Q-Flash Plus
-
1 × Reset
Physical Specifications
Product Dimensions
-
Width: 244 mm
-
Length: 305 mm
-
Net Weight: 1.31 kg
Package Dimensions
-
Width: 27 cm
-
Length: 33.5 cm
-
Height: 8 cm
-
Gross Weight: 1.60 kg
Features
-
PCIe Gen5 support
-
Supports Intel Core 14th / 13th / 12th processors
-
WIFI EZ-Plug design
-
WIFI Compass antenna positioning
-
EZ-Latch PCIe 5.0 ×16 slot
-
PCIe UD Slot with SMD Armor
-
Hybrid 8+2+1 Phases VRM solution
-
XMP Memory Module Support
-
GbE LAN and Wi-Fi 802.11ax
-
2 × PCIe 4.0 ×4 M.2 connectors
-
Rear USB-C 20 Gb/s
-
Smart Fan 6
-
Q-Flash Plus
Package Contents
-
Motherboard
-
Manual
-
1 × Antenna
-
2 × SATA Cables
-
M.2 Screws
-
I/O Shield
-
One Pack of M.2 Thick/Thin Rubber Pads
